Stacked column slide

The Stacked column slide type allows you to create a stacked column chart in your presentation by selecting board groups, an x-axis column, a "stacked by" column, and y-axis column. This slide type is ideal for visualizing data that is divided into segments within each category, showing both individual and cumulative values.

Key Features​

  • X-Axis, Stacked By, and Y-Axis Configuration:

    • X-Axis: Choose a column to represent the categories along the x-axis.
    • Stacked By: Select a column to segment the columns into stacks.
    • Y-Axis: Choose a column to represent the values of each stack.

  • Group By Time Period: This option appears when a date column is selected as the x-axis. You can choose a time period to group the dates in the x-axis column: Day (default), Week, Month, Quarter, Half Year, or Year.

  • Calculation Options: Determine how to calculate the y-axis values: Sum (default), Average, Median, Min or Max.

  • Display Settings:

    • Show Empty Values: Decide whether to include x-axis values that are empty. This feature is disabled by default.
    • Show Default/Unassigned Values: Choose whether to include default or unassigned x-axis value. This feature is disabled by default.

For details on supported columns for stacked column slides, refer to the Board Column Support section.

Example​

Here’s how a stacked column slide will appear in your presentations:

Stacked Column Slide Example
